Specifications

Model

UT202

AC Current (A)

2A/20A/200A/400A

±(1%+9)

AC Voltage (V)

2V/20V/200V/600V

±(1.2%+5)

DC Voltage (V)

200mV/2V/20V/200V/600V

±(0.8%+1)

Resistance (Ω)

200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ

±(1%+2)

Temperature (°C)

-40°C ～ 1000°C

±(1%+7)

Temperature (°F)

-40°F～1832°F

±(1%+8)

Features

Display Count

2000

Auto Range

√

Manual Range

Jaw Capacity

28mm

Diode

√

Auto Power Off

√

Continuity Buzzer

√

Low Battery Indication

√

Data Hold

√

MAX Mode

√

MIN Mode

Full Icon Display

√

Input Impedance for DCV

Around 10MΩ

√

General Characteristics

Power

1.5V Batteries (R03) ×2

LCD Size

35.6mm X 18mm

Product Color

Red and grey

Product Net Weight

220g

Product Size

210mm X 75.6mm X30mm

Standard Accessories

Battery, Test Lead, Carrying Bag,

Point Contact Temperature Probe

Standard Individual Packing

Gift Box, English Manual

Standard Quantity Per Carton

48pcs

Standard Carton Measurement

503mm × 485mm × 295mm

(0.072 CBM Per Standard Carton)

Standard Carton Gross Weight

24.8kg
