♦ Features
--Compact modular size,easy installation
-- Power voltage display
-- Real time monitoring of over- and undervoltage
-- Independent adjustable delay time for phase sequence, phase loss, overvoltage, undervoltage
-- Adjustable over- and undervoltage threshold and delay time
-- 100 Joules surge protection
♦ Protective Functions
-- Overvoltage
-- Undervoltage
♦ Typical Applications
• Refrigerator • Washing machine
• Other household appliances
♦ Technical data
|
Model |
VP-2166D |
|
Input circuit = Measuring circuit |
L,N |
|
Rated voltage |
120VAC,230VAC,50/60Hz |
|
Overvoltage threshold |
for 230VAC,220-280VAC for 120VAC,120-150VAC |
|
Undervoltage threshold |
for 230VAC,100-210VAC |
|
Turn-on delay time(reset time) |
3-999s adjustable |
|
Turn-off delay time |
0.04s |
|
Surge pretoection |
100 Joules |
|
Load current |
10A,15A,16A,20A,30A,45A |
|
Degree of protection |
IP20 |
|
Electrical durability |
50 000 cycles |
|
Mechanical durability |
20 000 000 cycles |
|
Dielectric strength |
>2kVAC 1min |
|
Weight |
130g |
|
Socket type |
EN,EU,AU, US,FR,ISL,SANS |
|
Dimensions (H x W x D) |
120X54X83mm |
